GSM12U24-P1J

GSM12U24-P1J

Sold out
$0.00 - $0.00
$0.00
$0.00 - $0.00
$0.00
Availability:
Out of stock
Quantity Prices
Quantity
Unit Price
10+
$0.00
20+
$0.00
50+
$0.00
100+
$0.00
200+
$0.00
*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Features

Universal AC input / Full range
Energy efficiency level VI
Medical safety approved (2 x MOPP)
Extremely low leakage current
No load power consumption < 0.075W(<0.1W for 18V/48V)
High efficiency up to 87%
Class II power (without earth pin)
Protections: Short circuit / Overload / Over voltage
Fully enclosed plastic case
100% full load burn-in test
3 years warranty

General Specification

AC input voltage range 80~264VAC ; 113~370VDC
AC inrush current (max.) Cold start, 60A at 230VAC
Overload protection 110%~140% rated output voltage, hiccup mode, auto-recovery
Withstand voltage I/P-O/P: 5656VDC
Working temperature -20~+70°C
Safety standards ANSI/AAMI ES60601-1/ES60601-1-1-11
EMC standards

FCC part 15/CISPR22 Class B
Length of output cable 100cm of UL2468, 18AWG for 5~7.5V; 120cm of UL2468, 22AWG for 9V; 180cm of UL2468, 24AWG for 12V~48V
Dimension (LxWxH) 62.2 x 27.4 x 45.5mm
Standard DC plug P1J: 2.1øx5.5øx11mm / C+, tuning fork type
packing 110pcs/13Kg
