DDR-60G-5

DDR-60G-5

Sold out
$0.00 - $0.00
$0.00
$0.00 - $0.00
$0.00
Availability:
Out of stock
Quantity Prices
Quantity
Unit Price
10+
$0.00
20+
$0.00
50+
$0.00
100+
$0.00
200+
$0.00
*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Features

Width only 52.5mm (3SU)
DC output adjustable ( 10%)
4:1 ultra wide input range
No minimum load required
Protections: Short circuit / Overload / Over voltage /Input reverse polarity / Input under voltage protection
4KVdc I/O isolation(Reinforced isolation)
Can be installed on DIN rail TS-35/7.5 or 15
-40~+85°C wide working temperature
Cooling by free air convection
3 years warranty

General Specification

Over current protection 110%~150% rated output power;Protection type:Constant current limiting, recovers automatically after fault condition is removed
Over voltage protection

5V:5.75~7V ; 12V:13.8~16.2V ; 15V:17.25~20.25V ; 24V:28.8~32.4V;

Protection mode:Shut down o/p voltage, re-power on to recover
REVERSE POLARITY By internal MOSFET, no damage, recovers automatically after fault condition removed
Withstand voltage I/P-O/P:4KVDC
Working temperature -40~+85°C (Refer to ""Derating Curve"")
Safety standards IEC 62368-1 (LVD) approved, Design refer to UL508
EMC standards With external components Compliance to EN55032 Class A for 1m I/O cable,Class B for 30cm I/O cable ;EN61000-3-,3，EN61000-4-2,3,4,5,6,8
Dimension (LxWxH)(mm) 52.5 x 90 x 54.5 mm
