PLM-25E-500

PLM-25E-500

Sold out
$0.00 - $0.00
$0.00
$0.00 - $0.00
$0.00
Availability:
Out of stock
Quantity Prices
Quantity
Unit Price
10+
$0.00
20+
$0.00
50+
$0.00
100+
$0.00
200+
$0.00
*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Features

230VAC only or Full range(up to 295VAC) models available
Built-in active PFC function
Constant current design
Protections: Short circuit
Cooling by free air convection
Fully isolated plastic case
Class II power unit, no FG
Class 2 power unit (for PLM-25-500/700/1050)
No load power consumption < 0.5W
High reliability, low cost
2 years warranty

General Specification

AC input voltage range Blank type: 110 ~ 295VAC 156 ~ 417VDC; E type: 180 ~ 295VAC 254~ 417VDC
AC inrush current (max.) COLD START 15A(twidth=50μs measured at 50% Ipeak) at 230VAC
DC adjustment range
Current adjustment range
Short circuit protection Hiccup mode, auto-recovery
Over temperature protection Hiccup mode, auto-recovery
Setup time Blank type: 500ms / 115VAC, 230VAC at full load; E type: 500ms / 230VAC at full load
Withstand voltage I/P-O/P: 3.75kVAC
Working temperature -30~+45ºC
Safety standards UL8750, ENEC EN61347-1,2-13
EMC standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547
Connection  DG235-7.2-2P
Dimension (LxWxH) (mm)
 145*38*22mm
Packing 60pcs/8.6Kg
PLM-25-1050
MEAN WELL

PLM-25-1050

$0.00
PLM-25-700
MEAN WELL

PLM-25-700

$0.00
PLM-25-350
MEAN WELL

PLM-25-350

$0.00
PLM-25-500
MEAN WELL

PLM-25-500

$0.00
PLM-40-1750
MEAN WELL

PLM-40-1750

$0.00
PLM-40-350
