DDR-60G-12

• Width only 52.5 mm (3SU)
• Output: 12Vdc, 5A, 60W
• Input voltage: 9~36Vdc

• Ultra-wide 4:1 input range

• -40 ~ +85°C wide operating temperature
• No minimum load required
• Adjustable DC output (10%)
• Cooling by free air convection.
• Can be installed on TS-35 / 7.5 or 15 DIN rail
• Protections: Short circuit / overload / overvoltage / reverse input polarity / undervoltage input protection
• 4KVdc I/O isolation (reinforced isolation)

Applications

• Industrial control system
• Semiconductor manufacturing equipment
• Industrial automation
• Electromechanical
• Wireless network
• Telecom or data communication system

Description

The DDR-60 series is a 60W DIN rail type DC-DC converter with key features including easy DIN rail installation, ultra-thin width (52.5 mm), ultra-wide 4:1 input voltage range, -40 ~ +85°C wide operating temperature, 4KVdc I/O isolation, adjustable output voltage (10%), and complete protective features... etc.
This series has two input options: 9 ~ 36V / 18 ~ 75V and various output options: 5V / 12V / 15V / 24V, making it suitable for industrial control, safety control, communication systems, and other fields. Suitable applications include DC step-up/down regulator, system isolation level enhancement, and voltage drop compensation over long cables, etc.
