EDR-75-12

• Output: 12V, 6.3A, 75.6W
  Adjustable voltage range: 12 ~ 14V
  Universal AC input / full range
  Protections: Short circuit / Overload / Overvoltage / Overtemperature
  Cooling by free air convection
  Can be installed on TS-35 / 7.5 or 15 DIN rail
  UL 508 (industrial control equipment) approved
  Industrial immunity level EN61000-6-2 (EN50082-2)
  100% burn-in test at full load

  Applications

  • Industrial control system

  • Semiconductor manufacturing equipment

  • Factory automation

  • Electromechanical devices

  Description

  EDR-75-12 is a cost-effective and slim 75W DIN rail power supply, specifically designed for installation on TS-35 / 7.5 or TS-35/15 mounting rails. With a compact width of only 32 mm, it provides a space-saving solution for cabinet integration. The unit supports a wide-range AC input from 90VAC to 264VAC and meets EN61000-3-2 standards for harmonic current regulation required in the EU.

  Constructed with a robust metal housing, the EDR-75-12 offers enhanced heat dissipation and achieves up to 88.5% efficiency. It operates reliably within a temperature range of -20°C to +60°C under natural air convection. For added safety, the power supply includes constant current mode overload protection, making it well-suited for inductive and capacitive loads. With comprehensive protection features and certifications such as UL508 and TUV EN62368-1, the EDR-75-12 is a reliable and competitive choice for industrial power applications.
