LRS-150-15

Overview

The LRS-150-15 is a 150W enclosed power supply delivering a stable 15V DC output at 10A. Built with a compact metal housing, fanless cooling design, and high efficiency, it is engineered for reliability in industrial automation, LED systems, communication devices, and general-purpose electronics that require consistent 15V DC power.

The LRS-150F-15 variant includes the same robust features with additional built-in remote ON/OFF control functionality, making it ideal for applications where external power management is required.

Key Features

• Output Power: 150W

• Output Voltage: +15V ⎓ 10A

• Universal AC input: 85 ~ 264VAC / 120 ~ 373VDC

• High efficiency up to 90%

• Built-in protections: Short circuit / Overload / Overvoltage / Overtemperature

• Fanless cooling by free air convection

• LED indicator for power status

• Compact size: 159 × 97 × 30 mm

• High reliability with MTBF over 700,000 hours

• Warranty: 2 years

• LRS-150F-15 extra feature: Remote ON/OFF control

Typical Applications

• Industrial control systems

• LED lighting and signage

• Security and surveillance equipment

• Communication devices

• General-purpose 15V DC electronics

• Applications requiring remote ON/OFF control (LRS-150F-15)
