LRS-150-36

Overview

The LRS-150-36 is a 150W enclosed switching power supply that delivers a regulated 36V DC output at 4.3A. With its slim, low-profile metal case, high efficiency, and fanless cooling design, it provides a reliable solution for industrial automation, LED systems, communication devices, and other 36V DC applications.

The LRS-150F-36 shares the same performance and specifications but includes a built-in terminal cover, offering extra safety by preventing accidental contact with output terminals. This makes it ideal for installations requiring enhanced protection.

Key Features

• Output Power: 154.8W

• Output Voltage/Current: +36V DC ⎓ 4.3A

• Universal AC input: 85 ~ 264VAC / 120 ~ 373VDC

• High efficiency up to 90%

• Protections: Short circuit / Overload / Overvoltage / Overtemperature

• Fanless cooling by free air convection

• LED indicator for power status

• Compact size: 159 × 97 × 30 mm

• MTBF: Over 700,000 hours

• Warranty: 2 years

• LRS-150F-36 specific: Includes terminal cover for added safety

Typical Applications

• Industrial control systems

• LED lighting and signage

• Communication devices

• Test and measurement equipment

• General-purpose 36V DC electronics
