LRS-350N2-36

The Mean Well LRS-350N2-36 is a 350W single-output enclosed switching power supply that delivers a regulated 36V DC output at 9.7A. It features high efficiency, built-in active PFC, and multiple protection mechanisms, making it suitable for demanding industrial and electronic applications.

✅ Key Features:

• Universal AC input: 90–132VAC / 180–264VAC, switch selectable

• Output: 36V DC ⎓ 9.7A, 349.2W rated

• High efficiency: up to ~91%

• Built-in active PFC (Power Factor Correction)

• Protections: Short circuit / Overload / Overvoltage / Overtemperature

• Cooling by built-in fan with automatic speed control

• LED indicator for power on

• Slim compact size: 215 × 115 × 30 mm

• Compliance with international safety standards (UL / CE / UKCA / EAC)

• Warranty: 3 years

💡 Typical Applications:

• Industrial automation systems

• CNC machinery

• LED signage and lighting systems

• Test and measurement equipment

• Security and surveillance systems

• General-purpose 36V DC applications

Datasheet:
