MDR-100-24

Key Features:

• Output Voltage: 24V DC

• Output Current: 4.2A

• Output Power: 100.8W

• Input Voltage Range: 85–264VAC (47–63Hz) or 120–370VDC

• Efficiency: Up to 88%

• Mounting Style: Standard DIN rail (TS-35/7.5 or 15)

• No Load Power Consumption: <0.75W

• Cooling Method: Natural air convection (fanless)

• Built-in Protections:

  • Short Circuit Protection (Hiccup mode, auto recovery)

  • Overload Protection (Constant current limiting)

  • Over Voltage Protection (Shut down, auto recovery)

• LED Indicator: Green LED for power-on

• Insulation Class: Class II (no FG terminal required)

• Compact Size: 40mm (W) x 125.2mm (H) x 113.5mm (D)

• Operating Temperature Range: -20°C to +70°C (derating may apply above +50°C)

• Safety Standards & EMC Compliance:

  • UL508, TUV EN62368-1 certified

  • CE marking

  • EMC: EN61000-6-2 (industrial immunity), EN61000-6-4 (emissions)
