MDR-40-24

• Key Features:

  • Output Voltage: 24V DC

  • Output Current: 0.83A

  • Output Power: 20W

  • Input Voltage Range: 85–264VAC (47–63Hz) or 120–370VDC

  • Efficiency: Up to 86%

  • Mounting Style: DIN rail TS-35/7.5 or 15

  • No Load Power Consumption: <0.75W

  • Cooling Method: Convection-cooled (fanless operation)

  • Built-in Protections:

    • Short Circuit Protection (Hiccup mode, auto recovery)

    • Overload Protection (Constant current limiting)

    • Over Voltage Protection (Shutdown, auto recovery)

  • Power Indicator: Green LED

  • Insulation Class: Class II (no functional ground required)

  • Housing Dimensions: 22.5 x 90 x 100 mm (W x H x D)

  • Operating Temperature: -20°C to +70°C (with derating above +55°C)

  • Safety Approvals:

    • UL508, TUV EN62368-1

    • CE compliant

    • EMC: EN61000-6-2 (immunity for industrial environments), EN61000-6-4 (emissions)
