PWM-200-24

Constant voltage PWM-style output with 1.47 kHz frequency
Output: 24V, 8.4A, 201.6W
Plastic housing with Class II design
Built-in active PFC function
Class 2 power unit
No-load power consumption < 0.5W
Fully encapsulated with IP67 protection level
Function options: 3-in-1 dimming (dimming to off)
Minimum dimming level 0.2% for DA type
Typical lifespan > 50,000 hours

Applications

• LED strip lighting

• Indoor LED lighting

• Decorative LED lighting

• Architectural LED lighting

• "HL" type certified for use in Class I, Division 2 hazardous locations

Description

The PWM-200 series is a 200W AC/DC LED driver that delivers constant voltage output using PWM-style modulation, ensuring consistent color temperature and brightness across all types of LED strips. Operating over a wide input range of 90 ~ 305VAC, the series includes models with output voltages of 12V, 24V, and 48V.

Thanks to its high efficiency—up to 91%—and fanless design, the PWM-200 series can operate at case temperatures ranging from -40°C to +90°C under natural air convection. The unit is fully potted and rated IP67, making it ideal for dry, damp, or wet environments.

Equipped with a 3-in-1 dimming function (0-10V, PWM signal, and resistance), the PWM-200 allows flexible dimming control by varying the output duty cycle. This makes it an excellent choice for precision-demanding LED strip lighting applications, both indoors and outdoors.
