XLG-100-L-DA2

XLG-100-L-DA2

$68.81
Availability: ✔ 2 in stock, Ready to ship
Output Voltage: 158V
Rated Current: 0.7A
Power Rating: 100W
Quantity Prices
Quantity
Unit Price
10+
$65.37
20+
$63.99
50+
$62.62
100+
$61.24
200+
$59.86
*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.
Place your order within --:--:-- to ensure shipment Today
Quantity

Features:

  • Wide input range 100~305V AC(Class I)
  • Full power output at 70~100% Constant power mode operation
  • Metal case with IP67, suitable for outdoor application
  • Surge protection with 6KV/4KV
  • DALI-2 Dimming with a minimum level 8%
  • Protection functions: SCP/OTP
  • Lifetime >50,000 hrs
  • 5 years warranty

General Specification

AC input voltage range

100 ~ 305VAC 142VDC ~ 431VDC

AC inrush current (max.)

COLD START 45A(twidth=330μs measured at 50% Ipeak) at 230VAC; Per NEMA 410

Over-voltage protection

320 ~ 390VAC (Shut down output voltage when the input voltage exceeds protection voltage, recovers automatically after fault condition is removed). Can survive input voltage stress of 440Vac for 48 hours

Withstand voltage

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC

Working temperature

Tcase = -40 ~ +90℃

Safety standards

UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13(EL) appendix J suitable for emergency installations(DC Input: 176-280Vdc) independent ,BS EN/EN62384;IS 15885(Part2/Sec13)(for XLG-100I-DA2 only); GB19510.1,GB19510.14; EAC TP TC 004; IP67 approved

Dimension (LxWxH)

140x63x32mm
