Features:
General SpecificationAC input voltage range 100 ~ 305VAC 142VDC ~ 431VDC AC inrush current (max.) COLD START 60A(twidth=500μs measured at 50% Ipeak) at 230VAC; Per NEMA 410 Over-voltage protection 320 ~ 390VAC (Shut down output voltage when the input voltage exceeds protection voltage, recovers automatically after fault condition is removed). Can survive input voltage stress of 440Vac for 48 hours Withstand voltage I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC Working temperature Tcase = -40 ~ +90℃ Safety standards UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 (EL) appendix J suitable for emergency installations(DC Input: 176-280Vdc) independent, GB19510.1,GB19510.14; EAC TP TC 004;IS 15885(Part2/Sec13)(for XLG-200I-DA2 only); IP67 approved Dimension (LxWxH) 180x63x35.5mm |
