PA-120N-27P

Name: PA-120N-27P
Brand: MEAN WELL
Availability: OutOfStock

$0.00

Availability: Out of stock

ℹ️ Lead time for quantities greater than shown, contact us

Quantity Prices

Quantity

Unit Price

10+

$0.00

20+

$0.00

50+

$0.00

100+

$0.00

200+

$0.00

*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Quick Specs

Output Voltage

27.6V

Rated Current

4.3A

Power Rating

118.68W

Waterproof

Non-waterproof

Dimensions

5.66 x 3.54 x 1.29 in

Weight

2.42 lbs

Features

AC input range selected by switch

Built-in passive PFC function compliance to EN61000-3-2

With AC ON-OFF switch

3 poles AC inlet with fuse holder

Protections: Short circuit / Overload / Over voltage / Over temperature

Charger type can be selected (Optional)

Charger for lead-acid batteries

2 color LED loading indicator

Open frame models available (Without safety approval)

Low cost, High reliability

2 years warranty

General Specification

AC input voltage range	88~132VAC / 176~264VAC(selectable by switch); 248~370VDC
AC inrush current (max.)	Cold start, 50A at 230VAC
Overload protection	90%~110% Constant current limiting, auto-recovery
Over voltage protection	108%~127% hiccup mode,auto-recovery
Setup, rise, hold up time	1000ms,50ms,16ms at full load
Withstand voltage	I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature	-10~+45ºC(refer to output derating curve)
Safety standards	UL60950-1,TUV EN60950-1,EN60335,EN60335-1,EN60335-2-29 approved
EMC standards	EN55022(CISPR22) Class B,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024
Dimension (LxWxH) (mm)	Case Type:180x96x 49mm;PCB:144x90x 33mm
Packing	16pcs / 17.9kg(without PFC); 16pcs / 20.1kg(with PFC)
