RCP-2000-12

RCP-2000-12

Sold out
$547.87 - $547.87
$547.87
$547.87 - $547.87
$547.87
Availability:
Out of stock
Quantity Prices
Quantity
Unit Price
10+
$520.48
20+
$509.52
50+
$498.56
100+
$487.60
200+
$476.65
*Import tariff is included in the listed price. You pay exactly what you see—no surprise fees at checkout. Discounts are applied automatically based on the total quantity added to your cart.

Features

Universal AC input / Full range
Built-in 5V/0.3A, 12V/0.8A auxiliary power
Built-in active PFC function
Protections: Short circuit / Over current / Over voltage Input under voltage / Over temperature
Forced air cooling by built-in DC fan
High power density 21.4W/inch3
1U low profile: 44mm
Withstand 300VAC surge for 5 secs.
Active current sharing up to 6000W (3 units) in one 19"" rack, 3 racks max. can be operated in parallel (up to 9 units)
Remote control for single unit
Built-in remote sense function
Hot-swap operation
Internal OR-ing FET
PMBus serial communication
AC OK and DC OK signal, fan fail, OTP alarm signal
3 years warranty

General Specification

AC input voltage range 90~264VAC
DC adjustment range -12%~+15% rated output voltage
Overload protection 105%~125% constant current limiting, shut off after 5 sec., re-power on to recover
Over voltage protection 120%~145% rated output voltage
Setup, rise, hold up time 1500ms, 60ms, 10ms at full load and 230VAC
Withstand voltage I/P-O/P:3kVAC, I/P-FG:1.5kVAC, 1 minute
Working temperature -40~+70°C (refer to output derating curve)
Safety standards UL60950-1, TUV EN60950-1 approved
EMC standards EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 heavy industry level
Dimension (LxWxH) (mm) 295x 127x 41 mm
Packing 2kg (single unit of RCP-2000); 11.5kg (empty rack)
CASE: 974A
